NM500 Wear Chaic

Wear resistant steel plate

Length

4m-12m or as required

Width

0.6m-3m or as required

Thickness

3-300mm

Standard

AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.

Technique

Hot rolled

Surface Treatment

Clean, blasting and painting according to customer requirement

Thickness tolerance

±0.1mm

Material

NM360, NM400, NM450, NM500, NR360, NR400, AR400, AR450, AR500,AR550
XAR400, XAR450, XAR500, XAR600, QUARD400, QUARD450, QUARD500
FORA400, FORA500, RAEX400, RAEX450, RAEX500, JFE-EH360, JFE-EH400, JFE-EH500

Application

It is widely used in mining machinery,environmental protection machinery,
cement machinery, engineering machinery etc due to it is high wear resistance.

Shipment time

Within 15-20 workdays after receiving deposit or L/C

Export packing

Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required.

Steel/Grade

C

Si

Mn

P

S

AL

Cr+Ni+Mo

Nb+V+Ti

NM360/AR360

0.10-0.30

0.20-0.40

1.00-2.00

≤0.015

≤0.003

≥0.20

<0.6

Trace Amount

NM400/AR400

0.10-0.40

0.20-0.40

1.00-2.00

≤0.015

≤0.003

≥0.20

<0.9

NM450/AR450

0.10-0.40

0.20-0.40

1.00-2.00

≤0.015

≤0.003

≥0.20

<1.2

NM500/AR500

0.10-0.40

0.20-0.45

1.00-2.00

≤0.015

≤0.003

≥0.20

<1.5

NM550/AR550

0.10-0.50

0.20-0.45

1.00-1.50

≤0.015

≤0.003

≥0.20

<2.0

NM600/AR600

0.10-0.50

0.20-0.45

1.00-1.50

≤0.015

≤0.003

≥0.20

<2.5
